Resolve caravan diesel heater issues fast with our troubleshooting guide. Don’t let malfunctions disrupt your travel plans. Experiencing problems with your caravan diesel heater can be bloody frustrating – after all you just want to keep warm! Whether you’re gearing up for a cross-country adventure or simply looking to stay warm on a weekend getaway, a malfunctioning caravan diesel heater can put a damper on your plans. That’s why we’ve created this comprehensive troubleshooting guide to help you identify and resolve common problems with your caravan diesel heater quickly and efficiently.

Understanding Your Caravan Diesel Heater

Before diving into troubleshooting it’s essential to have a basic understanding of how your caravan diesel heater works. These heaters operate by burning diesel fuel to generate heat which is then circulated throughout your caravan via a series of ducts and vents. While they are generally reliable and efficient, like any mechanical system they can experience issues from time to time.

Installed Heater

Troubleshooting Chinese Diesel Heater Problems

Fuel Troubleshooting

• Clear Fuel Line: Ensure the fuel line is free from obstructions like air bubbles or cracks.
• Air Purge: It may take several start-ups to purge air from the line completely.
• Fuel Flow: Confirm fuel delivery to the heater unit.
• Diesel Gel Prevention: Prevent diesel gelling in low temperatures by using quality fuel filters.
• Resetting: For E-10 errors, reset the heater by removing and reinserting the fuse.

Power Troubleshooting

• Inverter and Voltage: Utilize a minimum 150-watt inverter and ensure at least 12.5 volts of power.
• Battery Check: Verify battery charge levels.
• Wiring Inspection: Ensure proper wiring connections, especially if extended wiring is involved.
• Glow Plug and Sensor: Check the glow plug and consider sensor replacement if necessary.

Air & Exhaust Troubleshooting

• Blockage Detection: Remove exhaust and air inlet pipes to detect blockages.
• Pipe Cleaning: Clean or replace obstructed pipes and mufflers.

Blown Fuses

• Fuse Replacement: Replace blown fuses promptly.
• Glow Plug Inspection: Replace the glow plug if causing short circuits.
• Fan Check: Ensure the fan is functioning properly to prevent overloading.

Diesel Heater Control Screen And Module

Chinese Diesel Heater Blowing Smoke

Is your heater emitting smoke? Follow these steps for troubleshooting:

• Blockage Check: Inspect air inlet, exhaust pipe, and muffler for blockages.
• Fuel Level: Top up fuel if white smoke indicates insufficient ignition fuel.
• Exhaust Pipe Length: Restore original exhaust pipe length to optimize performance.

Diesel Heater Error Code Table

Common Error Codes

Error Code E-01: Ignition Failure

If you’re seeing error code E-01 on your caravan diesel heater it indicates an ignition failure. This could be caused by a variety of factors, including a dirty or faulty ignition electrode, a clogged fuel line, or insufficient fuel supply. To troubleshoot this issue, start by checking the ignition electrode for any signs of dirt or corrosion. If necessary clean the electrode with a soft brush or replace it altogether. Next, inspect the fuel line for any obstructions and ensure that an adequate supply of diesel fuel is reaching the heater.

Error Code E-02: Overheating

Error code E-02 indicates that your caravan diesel heater is overheating. This can be a serious issue that poses a fire risk if not addressed promptly. The most common cause of overheating is a blocked air intake or exhaust vent, which restricts airflow and prevents proper heat dissipation. To remedy this problem, carefully inspect both the air intake and exhaust vents for any obstructions, such as debris or insect nests. Clear away any blockages and ensure that the vents are free to allow airflow.

Typical Chinese Diesel Heater

Error Code E-03: Fuel Pump Failure

If your caravan diesel heater is displaying error code E-03, it points to a failure of the fuel pump. This can occur due to a variety of reasons, including a clogged fuel filter, a malfunctioning fuel pump motor, or an electrical issue. Start by checking the fuel filter for any signs of contamination or blockage. If the filter appears dirty or clogged, replace it with a new one. Next, test the fuel pump motor to ensure that it is receiving power and functioning correctly. If necessary, consult the manufacturer’s manual for troubleshooting steps specific to your model of heater.

Additional Troubleshooting Tips

In addition to the common error codes mentioned above, there are several other troubleshooting steps you can take to address issues with your caravan diesel heater:

• Check the Thermostat: Ensure that the thermostat is set to the desired temperature and functioning properly. If the thermostat is faulty, it may not accurately control the heater’s operation.
• Inspect the Wiring: Examine the wiring connections for any signs of damage or corrosion. Loose or damaged wires can prevent the heater from receiving power or communicating with the control panel.
• Verify Fuel Quality: Use high-quality diesel fuel to prevent issues such as clogs or contamination in the fuel system. Avoid using old or contaminated fuel, as this can lead to performance problems.
• Clean the Exhaust Pipe: Periodically inspect and clean the exhaust pipe to remove any build-up of soot or debris. A clear exhaust ensures proper ventilation and helps prevents carbon monoxide build-up inside your caravan.

Conclusion

Encountering issues with your caravan diesel heater can be frustrating. However with the right troubleshooting steps, you can quickly diagnose and resolve common problems. By familiarising yourself with error codes, inspecting key components, and performing routine maintenance you can keep your heater running smoothly and enjoy a comfortable travel experience. If you have problems that can’t be resolved through troubleshooting contact a qualified technician for help. By following these guidelines, you can efficiently diagnose and resolve common issues, ensuring optimal performance and longevity for your diesel heater.

List Of Australian Caravan Brands

Adventura Caravans, Adventure Caravans, Aliner Caravans, Alpha Fibreglass, AOR (Australian Off Road Caravans), Apollo Caravans, Aussie Wide Caravans, Australian Motor Homes Pty Ltd, Australian Off Road Caravans, Avan Campers, Avan Caravans, Avida RV, Bailey Caravans, Ballina Campervans, Beachmere Caravans, Big Red Caravan Co., Billabong Custom Caravans, Black Series Caravans, Broadwater Caravans, Bushtracker Caravans, Camprite Campers, Caravan Manufacturer, Caria Caravan Trailer, Challenge Camper Trailers Caravans, Chapman Caravans, Classic RTM Caravans, Concept Caravans, Coromal Caravans, Creative Caravans, Crusader Caravans, Customline Caravans, Davsher Caravans, Desert Edge Trailers, Designer Vans Caravans, Discoverer Campers, Dreamhaven Caravans, Dreamland Trailers, Driftaway Caravans, Dryden Trailers Caravans, Eagle Caravans, Elddis Caravans, Elross Caravans, Emerald Caravans, Evernew Caravans, Exodus Campers, Ezytrail Campers, Ezytrail Caravans, Galaxy Caravans, Goldstream Recreational Vehicles, Goldstream RV, Golf Caravans, Grand Tourer Caravans, Heaslip Campers, Horizon Motorhomes, I & D Industries, Imperial Caravans, Jayco, Jayco Caravans, Jurgens Australia, Jurgens Caravans, Kea Campers Australia Caravans, Kingdom Caravans, Knaus Caravans, La Vista Caravans, Lifestyle Leisure RV, Limit Seeker Camper Trailers Caravans, Lotus Caravans, Majestic Caravans, Mandurah Caravans, MARS Campers, MARS Caravans, May West Caravans, Melbourne RV, Metro Caravans, Millard Caravans, Montana Caravans, New Age Caravans, Nova Caravans, Olympic Caravans, Opalite Caravans, Outback Caravans, Paradise Caravans, Paradise Motor Homes, Paramount Caravans, Regal Caravans, Regent Caravans, Retreat Caravans, Rhinomax, Rivenlee Caravans, Roadstar Caravans, Roma Caravans, Royal Flair Caravans, Shasta Caravans, Snowy River Caravans, Spaceland Industries Caravans, Spinifex Caravans, Suncamper Caravans, Sunland Caravans, Sunliner Recreational Vehicles, Supreme Caravans, Swagman Aust Caravans, Toy Haulers Manufacturer, Track Trailer, Trackabout Caravan Co., Trailblazer Caravans, Trailblazers RV Caravans, Trailer Manufacturer, Trailstar Caravans, Trakka, Trakka Caravans, Trakmaster Caravans, Travelhome, Traveller Caravans, Truelux 5th Wheel, Universal Caravans, Vanguard Caravans, Victory Caravans, Western Caravans, Windsor Caravans, Winnebago Industries, Wirraway Motorhomes, Zone RV

The essential guide to caravan levelling ramps and getting level fast. How to use and benefit from these indispensable tools for stability. Caravan levelling ramps used in conjunction with the awesome Elam Level app make it fast and simple to get your caravan level first time every time.

Introduction to Caravan Levelling Ramps

Caravan levelling ramps are a must-have accessory for your caravan. Caravan levelling ramps play a crucial role in ensuring stability and safety when parking your caravan on uneven ground. In this guide we’ll explore everything you need to know about caravan levelling ramps, from their importance to tips for choosing and using them effectively.

Caravan Levelling Ramps Dual Axle Caravan

Importance of Using Caravan Levelling Ramps

1. Ensure Stability: Levelling ramps help to keep your caravan level on uneven ground, preventing uncomfortable tilting and swaying.
2. Prevent Damage: Parking on uneven surfaces without levelling ramps can put undue stress on your caravan’s frame and suspension, leading to potential damage over time.
3. Enhance Comfort: A level caravan means you won’t roll out of bed in the middle of the night and you peas won’t all end up on one side of your dinner plate! By levelling your caravan, you create a more comfortable living environment inside.
4. 3 Way Fridge Operation: It’s crucial to effective operation of your 3 way fridge that your caravan is both level and stable. If your caravan level is out of whack then your 3 way fridge won’t work. Level caravan equals cold beer.

Types of Caravan Levelling Ramps

1. Single Axle Levelling Ramps: Designed for caravans with a single axle, these ramps offer ease of use and portability. They are ideal for smaller caravans and provide adequate support on most terrains.
2. Double Axle Levelling Ramps: Suitable for caravans with dual axles, these ramps offer increased stability and support across a wider surface area. They are built to accommodate heavier loads and provide added durability.

Caravan Levelled On Sloping Ground

How To Choose The Right Levelling Ramps For Your Caravan

1. Consider Weight Capacity: Ensure the levelling ramps you choose can support the weight of your caravan.
2. Check Compatibility: Check that the ramps are compatible with your caravan’s axle configuration. Make sure with dual axle caravans that the ramp will fit between the first and second wheel. Lots of ramps come in two sections for this reason.
3. Look for Durability: Invest in quality levelling ramps made from sturdy materials to withstand rugged terrain.
4. Wheel Chocks: Look for caravan levelling ramps that include working wheel chocks. No point in getting everything level only to have it roll back off the ramps.
5. Consider Additional Features: Look for ramps with anti-slip surfaces and safety features for added peace of mind.

Jockey Wheel Used In Conjuction With Caravan Levelling Ramps

Tips for Using Caravan Levelling Ramps Effectively

1. Assess the Slope: Before setting up, assess the slope of the ground and determine the low side. Pay consideration to whether your ramps have enough height to provide required levelling.
   Position Ramps Correctly: Position the levelling ramps perpendicular to the direction of travel and drive onto them slowly and steadily.
   Secure Placement: Engage the handbrake and chock the wheels on both sides to prevent any movement.
   Use A Shovel: A shovel can be just as effective as ramps. For example if your ramps aren’t high enough to provide the levelling you need you can dig out under the wheels on the opposite side to the ramps for additional height adjustment.

eLam Level Screenshot

The eLam Level App​

The developers of the eLam level app and levelling device idea came up after many family camping trips over the years. Finding a level spot to park the camper trailer or caravan can be a tedious guessing game. They developed the eLam app to save time setting up so you can focus on what matters. The portable levelling device connects to the app displaying clear calculations which detect level ground that suits your caravan and maximum caravan levelling ramp height.

Setting Up, Installing & Using The eLam Level App​

Setup and installation is easy and takes less than ten minutes and you only need to do it once – unless you changed caravans then you’d just do it again. I’ll go through it for you step by step. In certain instances it doesn’t matter if you do it in a slightly different order. It literally takes longer to read the below than it does to do.

eLam Level Installed In Internal Cupboard

Initial Setup

1. Download the app to your phone from Google Play or the Apple App Store.
2. Open the eLam Level app on your phone, select ‘Find Devices’ and connect to your device.
3. Select the ‘Settings’ button on the bottom navigation bar and enter your measured Axle length and Jockey wheel to axel length (as shown on the diagrams). For dual axle caravans measure from the centre of the 2 wheels to the jockey wheel.
4. Then select your closest ramp height and change any other setting to your preference.
5. Before positioning the eLam Level device in your caravan with the double sided tape, ensure the following steps have been completed:
   1. Place the eLam Level device on a horizontal surface with the arrow facing towards the front of the van. We have installed ours on a shelf inside an internal cupboard at the front of our caravan where it’s easy to get to.
   2. Try different locations in your van for best connection (preferably as close as practical to the front of the van and higher up if possible).
   3. Reverse towing vehicle close to the draw bar and from the drivers seat open the app and check that it connects. If you have trouble connecting you can try different device positions in the van.

Calibrating The Device

• Manually level your caravan or trailer using ramps or jack and the jockey wheel. Use whatever means necessary be it a spirit level, an app on your phone or the wife yelling at you when she reckons it’s level because we all know that when she says it’s level it’s level no matter what any other scientifically proven method says! Make sure you get it the way you want it to be because this is the “level setting” you’ll use from now on when levelling with the app. Don’t stress too much because if you need to change it later on just repeat this step.
• Once level select the “Calibrate” button in the app. Wait until calibrated. That’s it. You’re done.

Levelling Your Van

• Place your phone in a cradle on your car dash.
• Select the “Start Levelling” button when ready to find the best camping position.
• When the indicator is in the orange zone, you can place your ramp(s) on the lowest side of the van.
• Move the van slowly up the ramp/s allowing time for the indicator to settle at different points.

About The eLam Level Device

• Mount anywhere on a horizontal surface
• No wiring required
• 5+ year battery life (with moderate yearly use)
• Uses 2 x CR2477 batteries
• Bluetooth low-energy device
• Low power consumption when On and not connected (30uA)
• Extra-low power consumption when Off and not advertising (13uA)
• IP67 waterproof
• Dimensions 67mm x 41mm x 15mm
• Colour led to indicate device status
• Off – Red led flashes 3 times
• On – Blue led flashes 4 times
• Connected – Green LED stays on

The eLam Level App

There are two versions of the eLam Level App available.

eLam Level v1

• Caravan and RV support
• Connects to your eLam Level device
• Quick setup
• Accuracy to 0.1 degrees
• Colour indication when within ramp height
• Colour indication when level
• Find level ground while driving
• Configurable connection timeout
• Save hitch angle when uncoupling
• Can connect to multiple eLam devices
• Supports metric and imperial measurements
• Upgrade to eLam Level v2 with Cloud Support directly through the eLam Level app
• v1 Price As Of 26.04.2024 $125 incl GST

eLam Level v2 with Cloud Support

• Comes with the same features as the v1 model, with these additional features.
• Saves your device settings in the cloud
• Connect to your device from any Android or IOS device without losing your calibration or other settings
• No need to recalibrate or update your settings when connecting from different devices
• Support for device firmware upgrades
• Save Home and Away hitch angles
• Power of your device through the App
• Future enhancements will be available in this model only
• v2 Price As Of 26.04.2024 $165 incl GST

eLam Level App ​Specifications

• The eLam Level app and bluetooth low energy leveling device enables you to level your caravan or trailer without continually having to leave your car to check if you are level.
• Lets you know when you are parked in a position where you can place your wheel ramp and achieve a level position.
• No wiring required.
• Battery life 5 years .
• Adjustable device connection timeout through the app for extended battery life.
• Power supply: 2 x CR2477 button cell batteries
• Place anywhere in your caravan or trailer on a horizontal surface.
• IP67 waterproof ratting.
• Save hitch detach angle for easy reconnection to towing vehicle.
• Highly accurate to 0.1 degree.

​Conclusion: Improve Your Caravan Experience with Levelling Ramps & The eLam Level App

Investing in quality caravan levelling ramps is essential for ensuring stability and safety during your travels. By choosing the right ramps and using them effectively, you can enhance your caravan experience and enjoy peace of mind on every journey. Teaming up your caravan levelling ramps with the eLam portable levelling device makes it even faster and more accurate.
